Products

Eight product categories for scientific and engineering applications.

Choose a category to review systems, instruments, components, fabrication support, and laboratory supplies.

Categories With Photos

The product categories below follow the updated website requirement document.

Optical Table-top and Vibration Systems

Avanya Enterprise manufactures a wide range of solid breadboards, honeycomb breadboards, workstations, and optical tables. Tables and breadboards with rigid, passive, or active vibration damping options are available along with several damping techniques, skin thicknesses, and materials.

The components of the breadboard are designed to work together, allowing posts or rails to interface with the work surface. Additional components can be assembled or disassembled for repeated use across different applications and configurations.

Extreme Light Weight Optical Table (Magnetic)

30 mm thickness with 3 mm magnetic SS410 top skin.
2 mm epoxy-coated aluminium bottom skin.
Aluminium honeycomb core with M6 tapped holes at 25 mm grid.
Approx. +/- 0.1 mm flatness over 300 mm x 300 mm area.

Extreme Light Weight Optical Table (Non-Magnetic)

30 mm thickness with 3 mm non-magnetic SS304 top skin.
2 mm epoxy-coated aluminium bottom skin.
Aluminium honeycomb core with semi-solid epoxy bonding.
Matte-finish black side walls.

Light Weight Optical Table (Magnetic)

60 mm thickness with magnetic SS410 top skin.
Aluminium honeycomb core and M6 tapped holes at 25 mm grid.
Compressed wooden particle side walls to damp acoustic vibrations.

Standard Optical Table (Magnetic)

4 mm magnetic SS410 top skin and 4 mm epoxy-coated steel bottom skin.
0.25 mm aluminium honeycomb core.
25 mm grid tapped holes and matte-finish side walls.

Standard Optical Table (Non-Magnetic)

4 mm non-magnetic SS304 top skin.
4 mm epoxy-coated non-magnetic steel bottom skin.
Designed with aluminium honeycomb core and acoustic damping side walls.

Customise Optical Table

We can quickly provide custom configurations for optical breadboards and platforms, including custom mounting hole patterns, through-holes, and shapes to suit specific applications and budgets.

Active Vibration Isolation Support

Active vibration isolation support is designed for demanding optical table installations where low resonant frequency and load handling are important.

Vertical resonant frequency: 1.25 Hz.
Horizontal resonant frequency: 1.0 Hz.
Vertical transmissibility at resonance: 10 dB.
Horizontal transmissibility at resonance: 12 dB.
Vertical transmissibility at 5 Hz: -20 dB (90%).
Maximum load capacity for set of four: 600 - 800 kg.
Height adjustment range: -25 mm to +25 mm.
Self-levelling repeatability: +/- 0.5 mm.
Height: 700 mm; maximum air pressure: 80 psi.

Passive Vibration Isolation Support

In PVIS series passive vibration isolation systems, isolated legs are interconnected by pneumatic tubes for air filling. Air is filled through the inlet valve and uniformly distributed to all isolator legs.

Recommended air pressure: 25-35 PSI.
Air filter supports moisture-free air supply.
Air should be filled at least once a month.
Vertical and horizontal natural frequencies: 4 - 8 Hz.
Designed to isolate vibrations in the critical 10 - 50 Hz range.

Rigid, Non-Isolating Support Frames

These all-steel frames provide a cost-effective solution for supporting optical breadboards in laboratory or production environments where vibration isolation is not critical.

Sturdy all-steel construction.
800 mm frame height.
Load capacity: 700 kg.
Levelling pad and levelling feet adjustment range: +/- 25 mm.
Can be upgraded to active isolation using AVIS supports.

Overhead Shelves, Optical Enclosures, and Blackout Curtain Systems

Avanya Enterprise offers optical table shelves for organized, ergonomic lab space. Free-standing overhead shelves can mount vibration-producing equipment above the optical breadboard and can be adjusted or positioned along the rail.

Optical enclosures feature black hardboard or acrylic panels with sliding door assemblies. Blackout curtain systems provide modular, customizable assemblies that can be mounted to the floor, ceiling, or wall for lab light control.

Lab Equipments

Avanya Enterprise manufactures innovative laboratory equipment and analytical equipment for different laboratory applications.

Optical Instruments

Optical teaching, training, and research instruments for education and laboratory applications.

Electronic Instruments

Electronic lab instruments and analytical equipment with compact, energy-efficient, and durable designs.

Laboratory Equipment

Water baths, chillers, incubators, hot air ovens, deep freezers, fume hoods, furnaces, and more.

Quality assurance

We are an ISO 9001:2015 certified company and our products comply with Indian standards such as certificate of compliance.

Opto-mechanical Components

Opto-mechanical supports, mounts, adapters, and accessories for optical and photonics applications.

Optics

Optical products and accessories for spectroscopy, microscopy, holography, thin films, research, and education.

Physics Lab Instruments

Physics laboratory instruments for educational, experimental, and demonstration setups.

Metrology Instruments

Measurement and inspection instruments for precision laboratory and engineering requirements.

Fabrication Work

Need-based fabrication support for scientific setups, components, frames, and custom configurations.

Lab Supplies and Kits

Lab supplies, kits, accessories, and supporting items for practical education and research workflows.
